Engineering Electric Crawler Bulldozer Swamp Dozer 63kpa
| Place of Origin | CHINA |
|---|---|
| Brand Name | XINXING CATHAY EMERGENCY |
| Model Number | T160H |
| Minimum Order Quantity | 1 Unit |
| Price | Bargain |
| Delivery Time | 45DAYS |
| Payment Terms | L/C, T/T |
| Supply Ability | 1/45DAYS |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Engine | WP10G178E355 | Operation Weight（Kg | 15738 |
|---|---|---|---|
| Rated Power (Kw/rpm) | 131/1850 | Overall Dimensions L×W×H (mm) | 5125*3416*3190 |
| Working Efficiency (for 40m Moving) (M3/h) | 255 | Fuel Consumption（g/KwH） | ≦ 215 |
| Max Torque (NM/rpm) | 830/1150 | Blade Type | Straight Shovel |
| Min.ground Radium（m) | 3.1 | Grade Ability（°） | 30 |
| Max.drawbar Pull（KN） | 144 | Forward（Km/H） | 2.7/3.7/5.4/7.6/11 |
| Name | Low Fuel Consumption Bulldozer | Keywords | Construction Bulldozer Truck |
| Highlight | Engineering crawler bulldozer,Electric crawler bulldozer,Engineering swamp dozer |
||
Product Description
131Kw Crawler Type Low Fuel Consumption Bulldozer Engineering Construction Machinery
Easy maintenances The structural parts inherit the excellent quality of mature products. The electric harnesses adopt seamless corrugated pipes and deconcentrators for branching, featuring high protection grade. The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability. The modular structure design of the machine features easy disassembling and assembling, simple repairs, low failure rate, and easy maintenances.
|
Engine |
WP10G178E355 |
|
Rated power (Kw/rpm) |
131/1850 |
|
Fuel consumption(g/KwH) |
≦ 215 |
|
Max torque (NM/rpm) |
830/1150 |
|
Forward(Km/H) |
2.7/3.7/5.4/7.6/11 |
|
Reverse(Km/H) |
3.5/4.9/7.0/9.8 |
|
Ground contact length (mm) |
2430 |
|
Shoe width (mm) |
510 |
|
Ground pressure (Kpa) |
63 |
|
Min.ground clearance (mm) |
400 |
|
Overall dimensions L×W×H (mm) |
5125*3416*3190 |
|
Blade dimensions W×H (mm) |
3416*1149 |
|
Blade digging angle(°) |
55 |
|
Blade max.tilt adjustment (mm) |
860 |
|
Blade max.ground clearance (mm) |
1095 |
|
Blade max.digging clearance(mm) |
532 |
|
Blade capacity (M³) |
4.5 |
|
Working efficiency (for 40m moving) (M3/h) |
255 |
|
System pressure (Mpa) |
13.7 |
1. Warranty time is 12 months.
2. Our after-sales engineers are experienced, they can make professional answers for the problems you may encounter, extend the life of trucks.We provide technical support for our trucks and whole life parts supply.
3. Tell us your shipping needs, our sales manager will customize the most suitable trucks for you according to your needs.
